Projector Home Cinema Video Projector 200 ANSI Android 14 WiFi / Bluetooth 1+8GB

V1 Smart Video Projector 200 ANSI Android 14 Automatic Keystone Correction WiFi / Bluetooth Compatible Home Theater, 1+8GB

【High-performance chip】Equipped with Allwinner H723 high-performance chip, supporting 8K hardware decoding for clearer and more realistic image quality.

【Advanced operating system】Running on the Android 14.0 system, providing smooth operation without lag, enhanced system security and support for many app stores.

【Flexible projection angle】Features a 180° stepless adjustable projection angle design, adaptable to different placement scenarios and meeting different space requirements.

【Wireless connection】Features dual-band WiFi 6 and Bluetooth 5.2 compatible technology, supporting wireless/wired connections for multiple devices and wireless screen mirroring for phones and tablets.

【Automatic Keystone Correction】Equipped with hardware-based keystone correction, supporting ±30% automatic adjustment for easy positioning and tilting of the projected image.

【Bright and Versatile】Projects at 200 ANSI lumens brightness, with a projection distance of 1-3.5 meters corresponding to screen sizes of 33-235 inches, perfect for home theater use.

【Quiet Operation】Designed for low noise, with a sound level of less than 25 dB, creating a quiet and comfortable viewing environment.

Specifications:

Optical Parameters

Light Source: LED

Physical Resolution: 1280 x 720P

Brightness: 200 ANSI

Uniformity: 67%

Contrast: 1000:1

Projection Ratio: 1.25:1

Optimum Projection Size: 40-120 inches

Aspect Ratio: 4:3, 16:9, 16:10

Focus Mode: Manual Focus

Noise Level: <25 dB (1 m)

Speaker: 8Ω 0.5 W

Machine Power: 39 W (Max)

Lifespan: 30,000 hours

Operating Temperature: -10 ℃ to 60 ℃

Storage:

Storage Temperature: -20 ℃ to 70 ℃

Storage Humidity: 10% to 80%

Main Product Parameters:

Product Name: Portable Projector

Model: V1

SoC: H723

CPU: Quad-core 64-bit ARM Cortex-A53

GPU ARM Mali-G31

Supports OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0

RAM 1GB

ROM 8GB

Supports video engine:

- H.265, up to 8K@24fps

- 10-bit HEVC MP@L6.1, up to 4K@30fps

- 10-bit VP9, ​​​​up to 4K@30fps

- 10-bit AVS2, up to 4K@30fps

- 8-bit AVC BP/MP/HP@L4.2, up to 4K@30fps

- MPEG1 MP/ML, MPEG2 MP/HL, MPEG4 SP/ASP L5, up to 1080P@60fps

- 10-bit AV1 MP/L5.1, up to 1080P@60fps

Main interface function

AC input 100-240V

USB port USB 2.0 HOST x 1

DisplayPort HD 2.0 input x 1

Audio interface AUX x 1

TF interface TF x 1

IR IR x 1

System parameters

System version Android 14

UI system CHIHI Launcher

WLAN supports 2.4G/5G WiFi 6

Bluetooth compatible supports BT 5.0+

Features

Languages ​​Simplified Chinese, Traditional Chinese, English, Russian, Spanish…

Projection mode Supports front projection and ceiling installation;

front projection and lifting;

rear projection and ceiling installation;

rear projection and rear mounting

Supports four-point correction

Supports screen zoom 60%-100%

Supports wireless screen projection

Other parameters

Machine size 94 x 91 x 165 mm

Package includes

1 x Projector

1 x Power cord

1 x Remote control

1 x English manual
